Technical Details

Mfg #

16018100

SKU

16018100

UPC

724920149273

NMFC #

130195SUB2

Weight

230 lbs.

Dimensions

35 × 31 × 27 inches

A-frame Construction

Tubular

Pivot Bolt

1.000 inch

Hydaulic Power Unit Construction

Integrated Block Design w/SAE Cartridge Valves

Hydraulic Hose

SAE 100R17-6

Hydraulic Power Unit HP

2.0 horsepower

Hinge

- inch

Angle Cylinder Size

1-1/2 x 6 inch

Lift Cylinder Size

1-1/2 x 6 inch

System Working Pressure

1850 poundpersqin

Angling Relief Pressure

3000 poundpersqin

Angle Cylinder Action

Single Acting

Chain

Grade 70 5/16 Transport Chain

Lift Mechanism

Chain Lift

Attachment System

Dual Foot Pedal Quick Mount

Connector Features

Overmolded w/Beryllium Copper Spring Cage Pins

Controller Type

Handheld Controller

Control Harness Features

4 Gauge

Plow Light Mount

Dual Stud
